Norwood Wall Lining and Cladding
Create your own environment with our range of aesthetically pleasing wall lining and cladding systems.
Our wall cladding systems accommodate fire performance, resistance to moisture, detailing around fenestration, openings, acoustics, environmental concerns and a host of other technical properties.
A highly versatile and adaptable solution for services, bulkheads, stylish lift reveals and decorative skirting’s, all available in brushed and PPC aluminium as well as stainless steel. Our panel options offer quick, cost effective solutions for Architects and Designers to specify high quality walls to meet the exacting demands of any client.
Solutions are offered in a wide range of natural and durable materials, delivering a visually stunning, high performance solution. Beautifully simple in its design, quick to install, and with a wide range of décors, textures and natural finishes.
Because of its modular design and highly configurable hardware array, wall lining solutions can be shipped to meet the most demanding of lead times, and installed far more quickly and effectively than traditional wall panel systems.
Unique designed panels can be integrated within the system incorporating back light effects or LCD displays, whilst a range of services can be concealed and housed within a clear space behind the panels.
Partition Thickness
Two-sided partition, from 60mm thick to various thicknesses
Cleanroom Classification
cGMP Grade B to Unclassified ISO4 – ISO8
Partition Finish
Pre-formed steel panels with a Foodsafe laminate on a galvanised substrate, with a bonded backing of plasterboard.
Various colours available, samples and data sheets can be provided on request.
Fire Ratings
Spread of Flame – Class O (BS: 476-6 & 7)
Up to 120min Fire Rating (BS: 476-22)
Acoustic Ratings
40dB to 54dB depending on insulation type
Structural Rating
– Medium Duty (BS: 5234)
– 3.0kN crowd pressure
U Values
Manufactured to clients’ specifications
Air Leakage
Pressure – Leakage
0-75Pa – 0.00L/s
80Pa – 0.03L/s
85Pa – 0.04L/s
90Pa – 0.06L/s
Other pressures are available on request.
Details & Tolerances
No core materials to panel void unless fire rated
Head Fixing: Telescopic steel section ceiling fixed (free-standing available).
Deflection Allowance: +/- 15.0mm, other tolerances available on request
Skirting or Recessed base can be provided to allow flooring to finish flush with panel face
Joint Treatment: Silicone or flush push in PVC gasket.
